Catwalk-bridge

No. 9000049

Assembly timedepends on construction
Installersdepends on construction
Foundations2x 1.40 x 0.80 x 0.80 m

smb-bridges are ideal additional elements to add that certain something to our framework units.

Of course are the bridges also available as a separate device. Depending on the length of the bridge are center supports or special support ropes and fittings required.

Bridge

Rope 16 mm
Catwalk connection width 160 mm
Catwalk width 185 mm
Parapet height 850 mm
Parapet width 800 mm
ladder step clearance 40 mm
ladder step 60 x 60 x 260 mm (acacia wood)
Standard lengths up to 6.00, anything longer than 6 m has to be in consultation.

Fixation: bracket/eye bolt M16

Entry support

Support construction out of steel tube 108 x 3,6 mm; protected against corrosion by galvanizing and subsequent powder coating RAL color.

Width (center) 800 mm

Entry height 400 mm
Post height of playground 1350 mm

The ladder steps out of acacia wood have the dimension of 60 x 60 mm.

All corners and edges are rounded. Acacia wood has a variety of characteristics that are ideal for outdoor use. The wood is hard, tough and elastic and does not require environmentally harmful impregnation. The durability is according to DIN EN 350-2 class 1, which is a long life.

We will also manufacture bridges according to your individual specifications.
