Zugspitze
No. 1178043
| Unit space area | 11.30 x 11.30 m |
| Safety space area | 14.30 x 14.30 m |
| Safety space area size | 195.03 m² |
| Height of unit | 7.40 m |
| Age range | 5+ |
| Number of users | approx. 60 |
| Free fall height | 2.50 m |
| Heaviest component | 240 kg |
| Total weight | 690 kg |
| Assembly time | 5.00 hours |
| Installation personnel | 3 persons |
| Foundations (amount of concrete) | |
| Mast | 1 (1.15 m³) |
| Tension points | 4 (7.20 m³) |
| Total amount of concrete | 8.35 m³ |
Additional elements such as seating nets to create quiet zones.
At a height of 7.4 m is also given a challenge for climbers.
Popular colors for steel parts
Beige
Colza yellow
Pastel orange
Flame red
Cobalt blue
Distant blue
Leaf green
Yellow green
Anthracite grey
Light grey
Terra brown
Pearl copper
Jet black
White aluminium
Pure whiteSelectable colors for ropes
Classic red
Missouri green
Royal blue
Cosmos black
Silver grey
Nature
Autumn yellowPossible additional elements
Download area
